Item: 5 Port 10/100Mbps Ethernet Switch
Item code: SW50010-D
FEATURES
 Built-in 5 Ports Fast Ethernet
Supports 200Mbps in Full Duplex Mode
Ideal for Fast Home Network, Gaming and Video
Easy Uplink on any Switch - No special lead needed
Sylish and compact design with Low Power consumption
Plug n' Play for all Computers, Media Centres, Game Consoles and more
SPECIFICATIONS
| Standards and Protocols |
IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IP |
| Basic Function |
Wire-speed Performance
MAC Address Auto-Learning and Auto-aging
IEEE802.3x flow control for Full-Duplex Mode and
backpressure for Half-Duplex Mode |
| MAC Address Table |
1k |
| Forwarding Rate |
10BASE-T: 14880pps/port
100BASE-TX: 148800pps/port |
| Transmission Method |
Store-and-Forward |
| Ports |
5 10/100Mbps Auto-Negotiation
RJ45 ports (Auto MDI/MDIX) |
| Network Media |
10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100ù STP (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100ù STP (maximum 100m) |
LED Indicators
|
Power, Link/Act (1, 2, 3, 4, 5) |
| Environment |
Operating Temperature: 0°C~40°C (32℉~104℉)
Storage Temperature : -40°C~70°C (-40℉~158℉)
Relative Humidity :10% ~ 90%, non condensation
Storage Humidity : 5%~95% non-condensing |
| Power |
External Power Adapter |
|
