Item: 24 Port 10/100Mbps Ethernet Switch
Item code: SW240010-R
DESCRIPTION
Get the performance your Network deserves with the new range of Dynamode 'Energy Efficient Ethernet' technology series of Fast and Gigabit Switches. Offering exceptional value for money, together with enhanced features so that your network will run faster, and for longer. Ideal for Networks of all sizes, the new range of Switches help reduce your Network Energy Consumption, thus reducing your Carbon Footprint and helping you to reduce your Network running costs in your environment. Ideal for Schools, Universities, Business and Home Users looking for that bit extra for there Network.
FEATURES
24-Port 10/100Mbps auto-sensing RJ45 Ports
Fully 802.3 and 802.3u Fast Ethernet compliant
Wire-speed Packet filtering for improved LAN speeds
Supports Pre-802.3az Energy Efficient Ethernet ability
Enhanced ASIC core enable up to 3.57Mbps Packet Forwarding
Supports non-blocking 'Store and Forward' packet routing for fast access
Built-in Memory Buffers with up to 2MB Buffer and up to 8M MAC addressing
1U high and 19" width in RFI protected enclosure with passive cooling
Supplied with Rackmount Kit
SPECIFICATIONS
Data Transfer Rates |
10Mbps and 100Mbps |
Protocols Supported |
802.3i 10BaseT
802.3u 100BaseT
802.3x Full Duplex Flow Control |
MAC Address Table |
8k |
Switch Fabric |
4.8Gbps |
Packet Filtering |
3.57Mbps |
Transmission Method |
Store-and-Forward |
Ports |
STP RJ45 (fully shielded) |
Power Consumption
|
9W (approx.) |
Net Weight |
1350g (approx.) |
Power Supply |
AC 100~240V 50/60Hz auto-sensing |
Operating Temperature |
0ºC ~ 45ºC ambient (approx.) |
Humidity |
5% ~ 95% (non-condensing) |
Storage Temperature |
0ºC ~ 70ºC |
Regulations |
FCC Part 15 Class A, CE, RoHS compliant |
|
